The Star shifting interface converter products include three major series:
Industrial serial optical fiber converter can convert the industrial site RS232/485/422 serial electrical signal into optical fiber signal transmission, to achieve long-distance transmission requirements, improve signal anti-interference ability;
Industrial serial cable converter, to achieve the industrial site RS232 and RS485/422 signals between the conversion, as well as multiple serial bus concentrator function, provide active/passive, isolated/non-isolated and other types of choice;
Industrial serial port repeater can realize the isolation relay function of RS232/485/422 signal in industrial field. By isolating and amplifies the signal, it can extend the communication distance and anti-interference.
● RS232 and RS485 bi-directional inter-conversion
● Serial port power theft, without external power supply
● unique serial port protection circuit, can be powered hot swap
● Intelligent flow control, zero delay automatic forwarding
● Signal line 600W/ms anti-lightning protection and 15KV anti-static protection.
Model | NS485F |
port | 1 channel RS-485/422→1 channel TTL active converter |
Power supply | external DC+5V power supply |
isolation type | Active non-isolated |
Working current | less than 10mA |
Communication rate | 300~115.2Kbps |
Communication distance | RS-232 side communication distance 5m RS-485/RS-422 side communication distance 1.2Km (19.2Kbps) |
max nodes | 128 nodes |
Protection voltage | 15KV electrostatic protection and 600W/ms lightning protection |
Weight | 0.5KG |
Size | 107mmx33mmx17mm (including terminals) |
Working temperature | -40℃～85℃ |
Certification | CE, FCC, RoHS |
