Industrial serial port server series products, mainly realize the data transmission between Ethernet and serial port (RS-232/RS-485/RS-422), it integrates the TCP/IP protocol stack, RS-232/RS-485/RS-422 devices that are not connected to the Internet can also be easily, flexibly and quickly connected to Ethernet. The series of products use high-performance ARM chip to ensure stable data transmission; Support a variety of working modes to meet different application requirements; Excellent anti-interference performance, suitable for harsh industrial environments.
Benefits:
1. Support 2-channel RS232/485 to 2-channel 10/100M Ethernet (can be cascaded).
2. Support Modbus RTU/ASCII and Modbus TCP conversion
3. Support DC9~60V non-polar input, dual power supply redundancy design, 6KV lightning protection
4. Modbus configuration-free pre-read, single serial port supports 256 Modbus RTU instructions, and the number of connections is synchronously extended to other transparent transmission modes
5. High-strength aluminum alloy shell, IP40 protection level, fanless shell heat dissipation, stable operation in harsh industrial environment of -40°C~+85°C
| Hardware parameters | |
| Product model | NS302G |
| CPU platform | 32-bit Arm Cortex-A7 core, up to 792MHz clock |
| Serial - Number of ports | 2CH RS232/485 |
| Serial-interface form | 6-position 3.81mm pitch industrial-grade terminal block |
| Serial port - communication rate | 300~460800bps |
| Serial port - data format | Support data bits: 7, 8 bits, stop bits: 1~2 bits, check bits: no check/ODD odd check/even check |
| Serial port - isolation voltage | 2KVAC/3KVDC |
| Number of RJ45 network ports | Two x 10Base-T/100Base-TX, support automatic flow rate control, full-duplex/half-duplex communication mode and MDI/MDI-X automatic recognition |
| RJ45 network port - isolation protection | 6KV lightning protection, 1.5KV isolation protection |
| Electricity | DC9~60V (support dual power redundant input, non-polar input) |
| Consumption | ＜1.8W（@DC12V） |
| ESD indicators | ± 8kV contact discharge, ± 15kV air discharge |
| Ingress protection | Surge Protection: Power : ±4kV/common mode, ±2kV/differential mode RS485: ±4kV/common mode, ±2kV/differential mode Ethernet port: ±6kV/common mode, ±2kV/differential mode EFT test: Power supply: ±4kV, communication port: ±2kV |
| Product Certification | CE、FCC、RoHS |
| Exterior dimensions | 140mmX35mmX100mm |
| Operating temperature | -40℃～+85℃ |
| Storage temperature | -40°C~+85°C 5%~95% RH (no condensation) |
| Software parameters | |
| Network protocols | IP、TCP、UDP、DNS、ARP、SNMP、SSH、ICMP、HTTP、DHCP Client、RFC2217、NTP、SMTP、TELNET |
| Configuration | IT SUPPORTS STATIC IP, DHCP, WEB CONFIGURATION/CONSOLE PORT SIMPLE NETWORK PARAMETER CONFIGURATION |
| Simple transparent transmission method | TCP Server/TCP Client/UDP Client/UDP Multicast/RealCOM/Pair Connection/MQTT |
| Modbus protocol | Modbus RTU/ASCII to Modbus TCP |
| Serial port data packaging mechanism | The interval and length can be set, and the maximum packing length is 1460bytes |
| Data encryption | DES/3DES/AES/RC2/RC4/RC5/BlowFish |
| SSL encryption | TLS1.0/TLS1.1/TLS1.2 |
| TCP connection | A single serial port supports up to 32 TCP client connections and 16 TCP server connections |
| Network caching | Send: 16Kbyte Receive: 16Kbyte |
| Serial port cache | Send: 16Kbyte Receive: 16Kbyte |
| Heartbeat pack | TCP keepalives are supported to customize the content of heartbeat packets |
| Registration Packet | Customize the content of the enrollment package |
| MQTT | In the tank |
| JSON | JSON is supported in Httpd Client, WebSocket Client, and MQTT modes |
| Average transmission delay | <10ms |
