Industrial wireless router series products are a kind of Internet of Things communication equipment for remote data acquisition and remote monitoring, widely used in power system, industrial monitoring, traffic management, weather monitoring, water dispatching, environmental monitoring, coal and oil and other industrial fields, is one of the essential key equipment in the development of industrial Internet of things. To provide users with convenient, fast and efficient device networking solutions. Moving Star industrial wireless router adopts high-end core chip design scheme, stable communication, reliable performance, powerful function, superior industrial protection ability, especially suitable for harsh industrial environment.
● Support WAN/LAN mode switching (routing mode 1WAN+4LAN or bridge mode 5LAN);
● Support Wi-Fi6 dual-band WLAN wireless local area network, support OFDMA+MU-MIMO technology;
● Supports five working modes of routing, AP, relay, bridge and client to meet different application scenarios;
● Support WEB management and AC management (AP mode) multi-platform management configuration;
● Support user isolation and adjustable transmit power, support country code setting;
● Support Wi-Fi short protection time interval, packet segmentation threshold and RTS threshold;
● Support wired rescue network, support SOS rescue SSID; Support multiple VPN virtual private network protocols (PPTP, L2TP, GRE, OpenVPN, IPSec), and support VPN encryption function.
| Product number | VS805WD-5GT | VS805WD-GF-4GT |
| Functional description | Industrial-grade full gigabit dual-band WIFI6 wireless router | |
| Power Specifications | ||
| Operating Voltage | DC12~60V (support dual power supply redundancy, non-polarity input) | |
| power consumption | <12.5W (@12VDC) | <14.5W (@12VDC) |
| lightning protection | CM soil 4kV, DM soil 2kV (1.2/50us) protection | |
| Network port specification | ||
| interface standard | Comply with IEEE802.3 standard | |
| Number of electrical ports | 5 (the WAN port supports POE power receiving) | 4 |
| Electrical port type | 10/100/1000Base-T(X) adaptive RJ45 port, automatic MDI/MDI-X connection | |
| Number of optical ports | / | 1 |
| Optical port type | / | 1000Base-X (SFP slot) |
| Wi-Fi specifications | ||
| wireless standard | Wi-Fi6 6th generation wireless network technology 2.4GHz 802.11b/g/n/ax; 5.8GHz 802.11a/n/ac/ax | |
| number of antennas | 2 | |
| Antenna interface | SMA interface (external screw inner hole) | |
| Theoretical Wi-Fi speed | 2.4GHz: 574Mbps，5.8GHz: 2402Mbps | |
| frequency | Frequency range: 2412GHz---2484MHz; 5180MHZ---5825MHz | |
| Modulation | DBPSK、DOPSK、CCK、OFDM、16-0AM、64-QAM、256-QAM、1024-QAM | |
transmit power | 2.4GHz; +16dBmHE40at-47dBDEVM +19dBmHE40at-450BDEVIV +24.5dBmMCS9HT40at-35dBDEVM +26dBmMCS7HT20/40at-30dBDEVM +28dBmMCSOHT20 | |
5.8GHz: +19dBmMCS11HE160at-43dBDEVM +16dBmMCS11HE80at-47dBDEVM +18dBmMCS11HE80at-43dBDEVM +23dBmMCS9VHT80at-35dBDEVM +24dBmMCS7HT20/40at-30dBDEVM +26dBmMCSOHT20 | ||
Receiver sensitivity | 2.4GHz: -69.0dBm(VHT40/MCS9/2SS) -63.0dBm(VHT40/MCS11/2SS) -68.5dBm(HT40/MCS9/2SS) -63.0dBm(HE40/MCS11/2SS) | |
5.8GHz: -64.5dBm(VHT80/MCS9/2SS) -59.0dBm(VHT80/MCS11/2SS) -64.0dBm(HE80/MCS9/2SS) -58.0dBm(HE80/MCS11/2SS) -58dBm(HE160/MCS9/2SS) | ||
| Physical Specifications | ||
| physical size | 140X54X110mm(H*L*W) (excluding DIN rail assembly size) | |
| installation method | DIN rail type | |
| Cooling form | Aluminum alloy single-rib chassis surface heat dissipation, no fan | |
| working environment | ||
| Operating temperature | -40°C~+75°C | |
| Storage temperature | 40°C~+85°C | |
| Working humidity | 5~95% (no condensation) | |
| Industry Standard | ||
| EMC | 61000-4-2(ESD),Level4EM CIEC61000-4-5(Surge),Level4 The network port supports 6KV lightning protection IEC61000-4-4(EFT),Level4 | |
| software parameters | ||
| Support web login and upgrade mirroring, support local system log, remote log, local log timed saving, etc. | ||
| Support external watchdog, button restart and factory reset function, support software immediate restart and timing restart function | ||
| Support routing, AP, relay, bridge and client five working modes; support virtual SSID and SSID hiding | ||
| Support user isolation and adjustable transmit power, support country code setting | ||
| Support Wi-Fi short protection time interval, data packet segmentation threshold value and RTS threshold value Support wired rescue network, when the AP mode device network is abnormal, you can log in https://6.6.6.6 to access the device through the wired network | ||
| Support SOS rescue SSID, AP mode device automatically releases SOS-XXXX rescue SSID when the network is abnormal (associated password is Admin-985#), use https://8.8.8.8 to access the device after association | ||
| Support firewall, port forwarding, IP/MAC filtering, domain name black and white list, DMZ and UPnP, DHCPServer | ||
| Support IP/MAC binding, static routing, PPPOE, static IP function | ||
| Network diagnosis function: support Ping, Traceroute and Tcpdump (network capture tool) | ||
| Support peanut shell intranet penetration and dynamic domain name resolution DDNS | ||
| Support VPNClient (PPTP/L2TP/OPENVPN/GRE/IPSEC) | ||
| Support VPNServer(PPTP/L2TP/IPSEC) | ||
| Support SNMP protocol and SNMPTrap report, support LLDP protocol | ||
