Protocol Standard

IEEE802.3(Ethernet), IEEE802.3u(100Base-TX&100Base-FX), IEEE802.3x (Flow control), IEEE802.3af/at.ect.

Switch Capability

Switching method

store and forward

Switch Bandwidth

14Gbps

Interface

Gigabit port

4x10/100/1000Base-T+1x1000Base-LX ports

Copper port parameters

Physical interface: RJ45 with shielding, IEEE802.3 standard

RJ-45 port: 10Base-T/100Base-TX/1000Base-T supports auto-negotiation function

Transmission distance:100 meters (using standard CAT5, CAT5e network cable)

PoE power supply mode: PSE end jumper method 1/2 (+), 3/6 (-)

PoE output power: single port PoE output≤30W

Fiber port parameters

Gigabit fiber port: 100/1000Base-F(X)

Wavelength: Multimode:850nm/1310nm;

Single mode:1310nm/1550nm

Transmission distance: Multimode fiber 850nm, 2km; 1310 nm, 2/5km

Single-mode fiber 1310nm, 20/40/60km; 1550nm, 20/40/60/80/120km

Connector Type: Shielded SFP Base

Transmission rate:1.25Gbps

Power parameters

Power input

Dual redundant power DC48~52V , reverse polarity protection

Power consumption

<3W@48V full load

Overcurrent Protection

Built-in

Working Environment

Operating temperature

-40°C~75°C

Storage temperature

-40°C~85°C

Ambient humidity

5%~95%

Physical Characteristics

Shell

IP40 protection, aluminum alloy shell

Installation

Standard 35mm DIN-rail Mounting

Dimension

118mm* 35mm*88mm (H×W×D)(Not including Din-rail kit)

Industry Standard

EMC

EN61000-4-2(ESD), Level 4

EN61000-4-3(RS), Level 4

IEC61000-4-5(Surge), Level4 ※The network port supports 4kV lightning protection

IEC61000-4-4(EFT), Level3

Impact

IEC60068–2-27

Falling

IEC60068-2-32

Shock

IEC60068-2-6

Warranty

Warranty

5 Years

Certification

CE, FCC, RoHS
